Shakespeare 4018-M 19′ VHF Antenna

10602
Shakespeare

$626.95 $279.75

1 in stock

Qty :
,

Description

THIS PRODUCT MUST SHIP TRUCK FREIGHT AND DOES NOT QUALIFY FOR ANY SHIPPING PROMOTIONS

Shakespeare Style 4018-M VHF Marine
19′ LENGTH, 9dB

PHASED 1/2-WAVE ELEMENTS IN A COLLINEAR ARRAY WITH A COAXIAL CHOKING SLEEVE TO SUPPRESS CABLE RADIATION

Same as Style 4018 with a special sleeve for mast mounting. Used primarily for land-based stations and on commercial vessels.

The top choice for charter boat captains and experienced sport fishing enthusiasts. This long-distance VHF antenna is rigid enough to stay erect in rough seas, yet exceptionally lightweight.

  • Brass and copper elements
  • Chrome-plated brass mid section ferrules and aluminum sleeve bottom ferrule
  • SO-239 connector at base
  • Suggested mount: Mast mount using supplied 1-1/3″ U-bolts. The 4018-M can be strapped to a larger mast if steel banding (not supplied) is used.
  • Two sections: Base 162"; Tip 66&quot:
  • Shakespeare Limited Warranty: 2 years

Technical Specifications:

Frequency:VHF Marine band
Bandwidth:(within 2.0:1 VSWR) 3 MHz
SWR:1.5:1 at 156.8 MHz
Impedance:(ohms): 50
Gain:9 dB
Max Input (Watts):25
DC Ground:NO
Termination:SO-239
Height (feet):19
Polarization:Vertical
Radiation pattern:Omni-directional

Quick Guide Litreture

Brochure Litreture

Antenna Band = VHF | Cable Length (Feet) = 20' | Cable Type = RG-58 | Color = White | Construction = Fiberglass | DB Gain (dB) = 9 dB | Ferrule Type = Chrome Plated | Length (Inches) = 19'

Additional information

Weight25 lbs
Dimensions228 x 2 x 2 in
Model Number4018-M
UPC719441100117
Warranty2 years
